China Factory Good Price 3 Feet Taper Drill Rod for Jack Hammer Drilling Manufacturers, Factories

1 / 5

China Factory Good Price 3 Feet Taper Drill Rod for Jack Hammer Drilling Manufacturers, Factories

Product Details

Customization:	Available
After-sales Service:	Repair or Replacement
Warranty:	6 Months

Send Inquiry

Product Description

📋

Basic Information

Model NO.

7degrees

Certification

ISO 9001:2000, ISO 9001:2008

Standard

Surface Treatment

Spray-Paint

Manufacturing Process

Forging

Material

Carbon Steel

Degree

7/11/12

Machine Type

Drilling Tools

Color

Red, Black, Yellow, White

Material Quality

95crmo 55simnmo 40simncrnimo 23crni3mo D6a

Origin

China

HS Code

82071990

Production Capacity

500000PCS/Month

📦

Packaging & Delivery

Package Size

30.00cm * 30.00cm * 30.00cm

Package Gross Weight

5.000kg

Transport Package

Wooden Case

🛠️

Product Description

Taper drill rod is used for rock drilling, blasting holes and other drilling works in the quarries, coal mines, traffic and other contractions. It works with taper drill bits and has different length for various applications. Our taper drill rods come in a variety of taper angles. Generally, the light duty rock drill usually use 7 taper or smaller taper angle, the heavy duty rock drill mainly use 11, 12 taper angle.

The basic theory is that taper drill rods and taper drill bits must be in the same tapered degree. We provide tapered rods in a full range of shank configurations and steel hex diameters for hand-held pneumatic drilling needs.

Steel grade: 95CrMo equivalent to SANDBAR20 or C253, Z708, sanbar23, 55SiMnMo
Shank size: hex.22mm × 108mm, hex.22mm × 159mm, hex.22mm × 80mm, hex.25mm × 108mm, hex.25mm × 159mm
Taper: 4°46', 6°, 7°, 11°, 12° degree etc
Length: 0.4m - 10m
Productivity: 50000MT / month

Shank hex. 22 mm (7/8") x 108 mm (4 1/4"). Rod hex. 22 mm (7/8). Flushing hole diameter 6.7 mm

ROD CROSS SECTION	Length (mm / foot-inch)		Weight approx. (kg)
4º46' taper angle
22H	800	2'7½"	2.8
22H	1600	5'3"	5.3
22H	2000	6'6¾"	6.5
22H	3200	10'6"	10.2
7º taper angle
22H	400	1'3¾"	1.6
22H	800	2'7½"	2.8
22H	1600	5'3"	5.2
22H	2000	6'6¾"	6.5
22H	3050	10'	9.7
22H	4000	13'1½"	12.6
11º taper angle
22H	800	2'7½"	2.8
22H	1525	5'	5.0
22H	2435	8'	7.8
22H	4000	13'1½"	12.6
22H	8000	26'3"	24.9
12º taper angle
22H	610	2'	2.2
22H	1220	4'	4.1
22H	2000	6'6¾"	6.5
22H	3965	13'	12.5
22H	4800	15'9"	15.1

❓

Frequently Asked Questions

1. What materials are used to manufacture these taper drill rods?

The rods are manufactured using high-quality Carbon Steel and specific steel grades such as 95CrMo (equivalent to SANDBAR20 or C253), 55SiMnMo, and others like 40simncrnimo to ensure durability in harsh drilling conditions.

2. How do I choose the correct taper angle for my project?

Generally, light-duty rock drills use a 7-degree or smaller taper angle. Heavy-duty rock drills primarily utilize 11-degree or 12-degree taper angles. It is essential that the rod and bit have the same degree for a proper fit.

3. What are the primary applications for these drilling tools?

Taper drill rods are ideal for rock drilling, creating blasting holes, and supporting operations in quarries, coal mines, traffic construction, and other heavy infrastructure projects.

4. What shank configurations and sizes are available?

We offer a full range of shank configurations, including common sizes like Hex 22mm x 108mm and Hex 25mm x 159mm. Lengths range from 0.4m up to 10m to meet various drilling requirements.

5. How are the products packaged for international shipping?

To ensure safety during transport, our taper drill rods are securely packaged in wooden cases or bundles, depending on the length and quantity of the order.

6. Are the products compliant with international quality standards?

Yes, the manufacturing processes follow GB standards and the production facility is certified under ISO 9001:2000 and ISO 9001:2008 quality management systems.
